NIBCO® N001165 TI-8 Gate Valve, 3/8 in Nominal, NPT End Style, Brass Body, Import
The solid wedge, integral seats and bi-directional service make the gate valve a good choice for irrigation services. Please refer to NIBCO technical data sheets, chemical resistance guides and catalogs for engineering and installation information. Choose NIBCO® gate valves for the most specified, versatile and economical valve option in light commercial and residential applications. The gate valve is backed by the NIBCO 2-year limited warranty.
-
BrandNIBCO®
-
UPC039923608727
-
Manufacturer Part NumberN001165
-
CountryUSA
-
Port TypeFull
-
Pressure Rating200 psi
-
Top to Inlet Center2.76 in
-
Trim MaterialBrass
-
Hand Wheel Diameter2.13 in
-
Nominal Size3/8 in
-
SeriesTI-8
-
Inlet to Outlet Length1.61 in
-
Softgoods MaterialGraphite/Rubber
-
Domestic/ImportImport
-
Body MaterialBrass
-
End StyleNPT
-
MediaCold Water, Oil, Gas and Saturated Steam
- Valve pressure rating 200 psi/14 bar non-shock cold working pressure
- Use in U.S. drinking water applications is prohibited after January 3, 2014
- The NIBCO brass gate valve features a screw-in bonnet for a durable, pressure-tight seal
- The non-rising stem gate valve with the cast iron handwheel offers positive shutoff
- Threaded ends allow for ease of installation
- Non-Rising stem
-
UNSPSC40141613
-
Package DescriptionEACH
-
Standards/ApprovalsASTM B16 Alloy C36000 Stem|ASTM B584 Alloy C85700 Body|PROP65: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
-
Warranty2 years Limited
-
