Browning® 1305002 Stock Shear Pin, 3/16 in Dia Neck, 1-1/8 in OD, For Use With Model SHH1 Hub, 3730 in-lb Torque, Steel
Browning® shear pin hubs are designed to shear a necked pin at a predetermined load. This protects equipment from overloads. Consisting of a hub assembly, a sprocket and shear pin, the shear pin bridges between the sprocket and hub assembly. The shear pin is available in load increments, so the closest one to your application requirements must be chosen. Resetting the shear pin hub is accomplished manually by replacing the shear pin. Best applied to applications where infrequent overloads are encountered.
-
BrandBrowning®
-
UPC662289285174
-
Manufacturer Part Number1305002
-
CountryUSA
-
MaterialSteel
-
Maximum Speed100 rpm
-
Torque Rating3730 in-lb
-
Neck Diameter3/16 in
-
Horsepower5.9 hp
-
Outside Diameter1-1/8 in
-
Suitable For Use WithModel SHH1 Hub
- Helps prevent damage to machinery due to sudden overload by shearing a necked pin at the predetermined load
- Sprocket rotates freely after pin breakage, allowing the drive to idle
- Universal mounting
- Single position
- Reversibility and repeatability
- Morse and Browning offer a complete line of Torque Overload Devices to protect machinery from overloads or jams
- Browning offers a complete set of replacement shear pins
- Replacement discs are readily available at 2 per pack
- Shear pins are available in a wide range of minimum shear strength
-
Alternative Part Number4H SH PIN
-
UNSPSC31161610
-
Package DescriptionEACH
-
Warranty1 Year
-
Instruction/Installation Manual
