CCI® Tri-Source® 02837 Right Angle GFCI Cord Set With Tri-Source® Cord Connector, 120 V AC, (3) 12 AWG Bare Stranded Copper Conductor, 25 ft L
Provide personal protection from ground faults and open neutral conditions anywhere electrical equipment is used. All GFCIs are compact, weatherproof/rainproof and engineered to handle rugged conditions of any jobsite. All models feature molded connectors, 12 or 14 gauge OSHA safety yellow cords, heavy duty strain relief, reinforced blades and pins, manual "Test/Reset" buttons and industrial grade relays.
-
BrandCCI®
-
UPC029892028374
-
Manufacturer Part Number02837
-
CountryUSA
-
Temperature Rating-35 to 66 deg C
-
TypeRight Angle
-
Conductor Size12 AWG
-
Conductor TypeBare Stranded Copper
-
Voltage Rating120 V AC
-
Amperage Rating15 A
-
Number of Conductors3
-
Insulation MaterialThermoplastic Elastomer
-
Jacket ColorYellow
-
Jacket MaterialTPE
-
Outside Diameter0.42 in
-
Length25 ft
-
Plug TypeNEMA 5-15
-
ColorBlue
-
Cord Length25 ft
-
Dimensions2.3 in H x 12 in W x 12 in D
-
Electrical Ratings125 V, 15 A, 1875 W
- Available in a variety of constructions from in-line to duplex to quad boxes
- All cord connected GFCIs are compact and engineered to handle rugged conditions of any jobsite
- 12 or 14 gauge OSHA safety yellow cords
- Made with rugged Seoprene or vinyl cable and thermoplastic protective housing
- Molded connectors, heavy duty strain relief and reinforced blades and pins
- Manual test/reset buttons and industrial grade relays
- Right angle models offer a variety of receptacles and cord lengths that are perfect where space is at a premium
- Duplex and quad boxes have high-impact resin with a slant-roof design to prevent water entry
- User attachable GFCIs convert your extension cords, tools and equipment to add GFCI protection
- All in-line and right angle GFCIs are weatherproof/rainproof
- Hard usage per the national electrical code cable rating
- Plug-in GFCI, NEMA 5-15P attachment plug configuration
- 3 x NEMA 5-15R cord connector configuration
- 1800 W maximum operating wattage
- Rainproof plug-in GFCI, outdoor use cordset
- 12/3 SJTW cable type
- Receptacles can accommodate large plugs
-
Alternative Part Number14880228-6
-
UNSPSC39121400
-
Standards/ApprovalsUL Listed|CSA Certified
-
Package DescriptionEACH
-
Specification Sheet
-
Owners/User Manual
