Fluke® FLUKE-323 Clamp Meter, 400 A, 600 VAC/VDC, 4000 Ohm, 30 mm Jaw, Backlit Display
True-RMS measurements and optimized ergonomics make the 320 series clamp meters the best general troubleshooting tools for commercial and residential electricians. The Fluke® 323 model is ideally suited for current measurements up to 400 A in tight cable compartments.
-
BrandFluke®
-
UPC095969623742
-
Manufacturer Part NumberFLUKE-323
-
CountryUSA
-
MaterialHard Plastic
-
Resistance4000 Ohm
-
AC Current Accuracy2% +/-5 Digits at 45 to 65 Hz, 2.5% +/-5 Digits at 65 to 400 Hz
-
Voltage Accuracy1.5% +/-5 Digits VAC, 1% +/-5 Digits VDC
-
Safety RatingCAT III 600 VAC, CAT IV 300 VAC
-
Dimensions8.15 in L x 2.95 in W x 1.34 in H
-
Display TypeBacklit
-
Jaw Capacity30 mm
-
Operating Temperature-10 to 50 deg C
-
Electrical Ratings400 A, 600 VAC/VDC
- True-RMS AC voltage and current for accurate measurements on non-linear signals
- Slim, ergonomic design, hold button
- Fluke® rugged, reliable, precise
- Resistance measurement up to 4 kOhm with continuity detection
- Resistance 400 Ohm/4000 Ohm with accuracy of (1% +/- 5 digits)
- <=70 Ohm continuity
| Competitor Name | Competitor Part Number |
|---|---|
| Grainger | 20E890 |
-
Alternative Part Number4152628
-
UNSPSC41113637
-
Package DescriptionBOX
-
Standards/ApprovalscCSAus Certified|CE Marking|ECCN 3A992|N10140 Certified
-
Owners/User Manual
