Power Team 10-TON HYD/CYLINDER RAM PTD C-104-C
Power Team® C104C C Series General Purpose Spring-Return Single-Acting Hydraulic Cylinder, 10 ton Load, 6-3/4 in H Min, 10.88 in H Max, 4.13 in
-
BrandPower Team®
-
Manufacturer Part NumberC104C
-
CountryUSA
-
Load Capacity10 ton
-
Piston Stroke4.13 in
-
Maximum Height10.88 in
-
Minimum Height6-3/4 in
-
TypeGeneral Purpose Spring-Return Single-Acting
-
SeriesC Series
-
Base Width2-1/4 in
- Aluminum bronze bearing reduces wear caused by aluminum bronze bearing reduces wear caused by off-center loads
- Removable rubber boots protect collar threads during transport and storage
- Solid steel cylinder body for durability
- Chrome plated piston rod resists wear and corrosion
- Wide range of accessories available that mount onto the piston rod, collar, or base
- Base mounting holes standard on 5 through 55 ton cylinders and optional on 75 and 100 ton cylinders
- Base mounting holes standard on 5 through 55 ton cylinder
-
UNSPSC24111800
-
Standards/ApprovalsANSI/ASME B30.1|CE Certified
-
Line Drawing
-
Catalog
-
Instruction/Installation Manual
