UNIVERSAL 120-VOLT 1-2 48" BULB BALLASTS UNV 446-LSLHTCP
No matter what the conditions require, operating at a variety of line voltages between 120 to 480 VAC, whether located in high ambient temperature environments (requiring a 90 deg C rating) or not, our family of Philips Advance Centium® ballasts are ideal for a wide variety of applications.
-
BrandAdvance
-
UPC781087074879
-
Manufacturer Part NumberICN2S40N35I
-
CountryUSA
-
Temperature Range70 deg C
-
MaterialMetal
-
Power Factor0.85
-
Total Harmonic Distortion10 %
-
Frequency Rating60 Hz
-
Minimum Starting Temperature50 deg F
-
Voltage Rating120 to 277 V AC
-
Wattage30 to 73 W
-
Amperage Rating0.25 to 0.61 A
-
Ballast Factor0.85
-
Number of Lamps2
-
Dimensions9.5 in L x 1.3 in W x 1 in H
-
Start TypeRapid
-
Lamp TypeT12
-
Lamp Wattage40 W
- High power factor
-
Alternative Part Number10002419
-
UNSPSC39101901
-
IDEA Index ID10002419
-
Package DescriptionEACH
-
Standards/ApprovalsRoHS Compliant|UL Listed|CSA Certified|DOE Certified|CSA-E Certified
-
Specification Sheet
