UNIVERSAL 2-BULB F-96-T-8 120/277-V BALLASTS UNV REL-2-P-59-SRHTP
Advance OPTANIUM IOP2P59N35I Electronic Fluorescent Ballast, T8 Slimline Lamp, 59 W Lamp, 120 to 277 VAC, Instant, 0.87 Ballast Factor
-
BrandAdvance
-
UPC781087135624
-
Manufacturer Part NumberIOP2P59N35I
-
CountryUSA
-
Temperature Range70 deg C
-
MaterialMetal
-
Power Factor0.98
-
Total Harmonic Distortion10 %
-
Frequency Rating50/60 Hz
-
Voltage Rating120 to 277 V AC
-
Wattage113/111 W
-
Amperage Rating0.4 to 0.95 A
-
Ballast Factor0.87
-
Number of Lamps2
-
Dimensions9.5 in L x 1.3 in W x 1 in H
-
DimmableNo
-
Start TypeInstant
-
Lamp TypeT8 Slimline
-
Lamp Wattage59 W
-
Enclosure TypeNEMA 23
- Reliable and energy efficient Philips Advance Centium® commercial grade specifications, plus added benefits of lamp striation reduction technology
- High power factor
-
Alternative Part Number13045324
-
UNSPSC39101902
-
IDEA Index ID13045324
-
Package DescriptionEACH
-
Standards/ApprovalsCSA Certified|UL Listed
-
Specification Sheet
