EATON Prism® 13150AL04 3/4-Wire Forward Viewing Photoelectric Sensor, Tubular Shape, 8 in, Red Laser Sensing Beam, 3 ms Response, Solid State Relay Output
Prism series 18 mm tubular sensors provide a flexible isolated output and twice the optical gain of other sensors in this product class. These cost-effective sensors offer forward- and right-angle viewing models that feature identical gain and optical characteristics for the best fit.
-
BrandEATON
-
UPC782113011325
-
Manufacturer Part Number13150AL04
-
CountryUSA
-
Frequency Rating50/60 Hz
-
Response Time3 ms
-
Type3/4-Wire Forward Viewing
-
Connection Type4-Pin Dual Key Micro
-
Mounting TypeSurface
-
Voltage Rating20 to 132 V AC/15 to 30 V DC
-
Wattage1.5 W
-
Amperage Rating80/110 mA
-
Sensing BeamRed Laser
-
Sensing MethodDiffuse Reflective
-
Sensing Range8 in
-
ShapeTubular
-
Size2.35 in L x 0.47 in W x 2.35 in H
-
Operating Temperature-13 to 131 deg F
-
Output TypeSolid State Relay
-
Enclosure TypeNEMA 1/2/3/4/4X/6/12/13
-
Light SourceLED
- Small size for use in a wide variety of applications and locations
- High sensing power for longer ranges and resistance to dust and dirt
- Adjustable gain control to ensure peak optical performance
- High noise immunity which greatly reduces problems associated with electrical noise
- AC/DC models which allow you to order and stock one model for both voltages
- Isolated outputs for wiring flexibility
- Short circuit protection is provided by an adjustable instantaneous only
- Highly visible output status LED
- Structural polyurethane foam body, PVC cable and polycarbonate lens
- 400 VAC maximum output isolation
- 200 VAC peak/180 VDC voltage switching capacity
- 10 uA maximum off-state leakage
- 25 Ohm maximum ON-state resistance
- Light steady when output is on
- 80 mA AC load, 110 mA at 132 VDC (derate to 100 mA at 180 VDC) current switching capacity
-
Alternative Part Number7324554
-
UNSPSC39121528
-
IDEA Index ID7324554
-
Package DescriptionEACH
-
Standards/ApprovalsUL Recognized,cUL Recognized
-
Warranty3 years
-
Catalog
-
Specification Sheet
