Enerpac® RCH606 Hollow Plunger Single Acting Spring Return Hydraulic Cylinder, 63.6 ton Advance Capacity, 4.88 in Bore, 6 in L Stroke, 12-3/4 in Retract, 3.61 in Dia Rod, 10000 psi Pressure
Enerpac® RCH606 Hollow Plunger Single Acting Spring Return Hydraulic Cylinder, 63.6 ton Advance Capacity, 4.88 in Bore, 6 in L Stroke, 12-3/4 in Retract, 3.61 in Dia Rod, 10000 psi Pressure
-
BrandEnerpac®
-
UPC662005302956
-
Manufacturer Part NumberRCH606
-
CountryUSA
-
Capacity63.6 ton Advance
-
FinishBaked Enamel
-
Port Size3/8-18 NPTF
-
Pressure Rating10000 psi
-
TypeHollow Plunger Single Acting Spring Return
-
Retract12-3/4 in
-
Rod Diameter3.61 in
-
Mounting TypeBase
-
SeriesRCH Series
-
Housing MaterialSteel
-
Dimensions5.25 in OD x 18.75 in H
-
Stroke Length6 in
-
Bore Size4.88 in
- Hollow plunger design allows for both pull and push forces
- Nickel plated, floating center tube on models over 20 ton increases product life
- Baked enamel finish for increased corrosion resistance
- Collar threads for easy fixturing
-
UNSPSC27121602
-
Standards/ApprovalsEAR99|ETC Certified
-
WarrantyLimited
-
Line Drawing
-
Specification Sheet
-
Warranty Information
-
Service Manual
-
Instruction/Installation Manual
