Power Team 20-TON SHORTY HYD/CYLINDER RAM PTD RLS-200
Power Team® RLS200 Heavy Duty Low Profile Welded Hydraulic Cylinder, 20 ton, 2-3/8 in Bore, 7/16 in L Stroke, 2 in H Retract, 1-1/8 in Dia Rod, 9029 psi
-
BrandPower Team®
-
Manufacturer Part NumberRLS200
-
CountryUSA
-
Capacity20 ton
-
Port Size21/32 in
-
Pressure Rating9029 psi
-
TypeHeavy Duty Low Profile Welded
-
Retract2 in H
-
Rod Diameter1-1/8 in
-
SeriesRLS
-
Dimensions3 x 4 in OD
-
Stroke Length7/16 in
-
Bore Size2-3/8 in
- Low height starting at 1.63 to 4.00
- Cylinder body, piston and gland nut are Power-tech treated for corrosion and abrasion resistance
- Standard domed piston rod (5-30 tons) or swivel cap (50-150 tons) minimize effects of off-center loading
- Unique heavy-duty spring
- Coupler is angled upward for extra clearance
- Provides fast piston return on all cylinders, except rls50
-
UNSPSC27121602
-
Standards/ApprovalsASME B30.1|CE Certified
-
Instruction/Installation Manual
-
Catalog
