Browning® 1213222 Minimum Plain Bore Type 4 Spur Gear, 4 Diametral Pitch, 14.5 deg Pressure Angle, 2 in W Face, 44 Teeth, 11 in Dia Pitch, 1-1/4 to 2-5/8 in Dia Bore, Cast Iron
Browning® offers a comprehensive line of off the shelf gears, including spur, miter and bevel as well as change gears. These are available in 20 deg pressure angle from 20 to 4 diametral pitch and 14.5 deg pressure angle from 48 to 3 diametral pitch. They are all designed to increase output, reduce costs and avoid the need for custom specials.
-
BrandBrowning®
-
UPC662289274673
-
Manufacturer Part Number1213222
-
CountryUSA
-
Face Width2 in
-
Pitch Diameter11 in
-
MaterialCast Iron
-
Pressure Angle14.5 deg
-
Gear Ratio1:1
-
TypeMinimum Plain Bore Type 4
-
Hub Diameter4-1/4 in
-
Hub Projection1-1/2 in
-
Diametral Pitch4
-
Number of Teeth44
-
Outside Diameter11-1/2 in
-
Bore Diameter1-1/4 to 2-5/8 in
-
Overall Length3-1/2 in
- Helical Gears are quieter than spur gears and give maximum smoothness on parallel shafts
-
Alternative Part NumberNCS444
-
UNSPSC31171707
-
Package DescriptionEACH
-
Standards/ApprovalsAGMA Standard
-
Warranty1 Year
-
Warranty Information
-
Catalog
