1-1/4" X 12" ZINC CONCRETE ANCHORS PWR7475
The Tough System® DS130 case features durable and thick structural foam walls, integrated water seal and rust-resistant metal latches. Storage pockets on the lid and 4 removable cups allow for storing small parts and side latches allow the product to be stacked to other modules of the Tough System® storage line.
-
BrandDeWALT®
-
UPC075352781402
-
Manufacturer Part Number7475SD1
-
CountryUSA
-
FinishZinc Plated
-
Thread Length7-3/4 in
-
MaterialCarbon Steel
-
Thread Size1-1/4-7
-
Thread TypeUNC
-
Maximum Work Thickness5-3/8 in
-
Minimum Embedment Depth5-3/8 in
-
TypeExpansion
-
Head TypeHex Nut
-
Diameter1-1/4 in
-
Drill Size1-1/4 in
-
Overall Length12 in
- Consistent performance in high and low strength concrete
- Anchor can be installed through standard fixture holes
- Length ID code and identifying marking stamped on head of each anchor
- Nominal drill bit size is the same as the anchor diameter
- Anchor design allows for follow up expansion after setting under tensile loading
- Side latches allow stacking product to other Tough System® modules
-
UNSPSC31162102
-
Includes
-
Package Description1/PK
-
Standards/ApprovalsICC-ES ESR-2818|ICC-ES ESR-2966|UL Listed|FM Approved|ASTM A563, Grade A|ASTM F844|ANSI B18.22.2|ASTM B633
-
Specification Sheet
Recently Viewed
The Tough System® DS130 case features durable and thick structural foam walls, integrated water seal and rust-resistant metal latches. Storage pockets on the lid and 4 removable cups allow for storing small parts and side latches allow the product to be stacked to other modules of the Tough System® storage line.
The Power-Stud anchor is a fully threaded, torque-controlled, wedge expansion anchor. It is available in threaded, rod hanger and tie-wire versions suitable for applications in solid concrete and grout filled concrete masonry. The carbon steel threaded version is suitable for a variety of applications. The drill bit diameter necessary for proper installation is the same as the anchor diameter.
The Wedge-Bolt+ anchor is a one-piece, heavy duty screw anchor with a finished hex head. It is simple to install, easy to identify and fully removable. The Wedge-Bolt+ has many features and benefits that make it well suited for many applications in a variety of base materials. The anchor is designed for consistent and reliable performance in cracked and uncracked concrete.
The Screw-Bolt™ anchor is a 1-piece, heavy duty Screw Anchor with a finished hex head or flat head (countersunk). It is simple to install, easy to identify and fully removable. The patented thread design, designed for use with standard ANSI drill bits, reduces installation torque and enhances productivity. The steel threads along the anchor body tap into the hole during installation to provide keyed engagement and allow for reduced edge and spacing distances. The Screw-Bolt™ is available as bright zinc plated or mechanically galvanized plating. Suitable base materials include normal weight concrete.
The Power-Stud®+ SD1 Anchor is a fully threaded, torque controlled, wedge expansion Anchor which is designed for consistent performance in cracked and uncracked concrete. Suitable base materials include normal weight concrete, sand lightweight concrete, concrete over steel deck and grouted concrete masonry. The Anchor is manufactured with a zinc plated carbon steel body and expansion clip for premium performance. Nut and washer are included.
The Power-Stud®+ SD1 Anchor is a fully threaded, torque controlled, wedge expansion Anchor which is designed for consistent performance in cracked and uncracked concrete. Suitable base materials include normal weight concrete, sand lightweight concrete, concrete over steel deck and grouted concrete masonry. The Anchor is manufactured with a zinc plated carbon steel body and expansion clip for premium performance. Nut and washer are included.
