DeWALT® 7404SD1 SD1 Expansion Wedge Anchor, 1/4 in Dia, 3-1/4 in OAL, 2-1/4 in L Thread, Carbon Steel, Zinc Plated
The Power-Stud anchor is a fully threaded, torque-controlled, wedge expansion anchor. It is available in threaded, rod hanger and tie-wire versions suitable for applications in solid concrete and grout filled concrete masonry. The carbon steel threaded version is suitable for a variety of applications. The drill bit diameter necessary for proper installation is the same as the anchor diameter.
-
BrandDeWALT®
-
UPC075352775913
-
Manufacturer Part Number7404SD1
-
CountryUSA|Canada
-
FinishZinc Plated
-
Tensile Strength1435 lb
-
Thread Length2-1/4 in
-
MaterialCarbon Steel
-
Thread Size1/4-20
-
Thread TypeUNC
-
Maximum Work Thickness1-7/8 in
-
Minimum Embedment Depth1-1/8 in
-
TypeExpansion
-
Head TypeHex
-
SeriesSD1
-
Shear Strength1255 lb
-
Diameter1/4 in
-
Drill Size1/4 in
-
Overall Length3-1/4 in
- Consistent performance in high and low strength concrete
- Length ID code and identifying marking stamped on head of each Anchor
- Ultimate load capacity: 1320 lb tensile strength when embedded in 2500 psi, 1435 lb tensile strength when embedded in 3000 psi and 1660 lb tensile strength when embedded in 4000 psi compressive strength concrete
- Nominal drill bit size is the same as the anchor diameter
- Anchor can be installed through standard fixture holes
- Anchor design allows for follow-up expansion after setting under tensile loading ultimate pullout 5440 lb
- Normal weight concrete, structural sand-light weight concrete, concrete over steel deck and grouted concrete masonry are applicable materials
| Competitor Name | Competitor Part Number |
|---|---|
| Grainger | 3A444 |
| Grainger | 3A444 |
-
Alternative Part Number7404SD1-PWR
-
UNSPSC31162102
-
IncludesNut and Washer
-
Package Description100/BX
-
Standards/ApprovalsICC-ES AC01, ESR-2818/2966|UL Listed|2015 IBC/IRC|ACI 318-14 Chapter 17|ACI 318-11/08 Appendix D|ACI 355.2|ASTM E488|Evaluated and Qualified by an Accredited Independent Testing Laboratory|FM Approved|ICC-ES AC193|UL EX1289
-
