5/8" X 6" STAINLESS STEEL CONCRETE ANCHORS PWR7334
The DeWALT® ToughBox® jobsite storage chest stores all of your professional and personal items on the jobsite. These storage chests will keep your tools secure with features such as a full length, staked and welded piano hinge and a 3-point locking mechanism to help prevent break-ins. Additional features have been added to make your job easy and efficient, including integrated rails to store DeWALT® Tough System® storage modules (not included). A grommet allows for electrical access, four way skids provide access from any side and two gas springs are standard on all of our units for safe operation of the lid. All DeWALT® ToughBox® jobsite storage chests include a powder coat finish for industrial strength resilience and protection from the outdoor elements.
-
BrandDeWALT®
-
UPC075352779225
-
Manufacturer Part Number7334SD4
-
CountryUSA
-
FinishZinc Plated
-
Thread Length4 in
-
Material304 Stainless Steel
-
Thread Size5/8-11
-
Thread TypeUNC
-
Maximum Work Thickness2-1/8 in
-
Minimum Embedment Depth2-3/4 in
-
TypeExpansion
-
Head TypeHex Nut
-
Diameter5/8 in
-
Drill Size5/8 in
-
Overall Length6 in
- Knurled mandrel design provides consistent performance in cracked concrete and helps prevent galling during service life
- Anchor can be installed through standard fixture holes
- Length ID code and identifying marking stamped on head of each anchor
- Nominal drill bit size is the same as the anchor diameter
- Anchor design allows for follow up expansion after setting under tensile loading
- Corrosion-resistant stainless steel anchors
-
UNSPSC31162102
-
Includes
-
Package Description1/PK
-
Standards/ApprovalsICC-ES ESR-2502|ACI 355.2/ASTM E488|ICC-ES AC193
-
