DeWALT® 01205-PWR Long Shell Expansion Anchor, 1/2 in Dia, 2 in OAL, 3/4 in Drill, Zamac Alloy
The Lag Shield™ is a screw style anchor designed for use with lag bolts. It is suitable for use in concrete and the mortar joints of block or brick walls. In harder masonry materials, short style Lag Shield™ are used to reduce drilling time. The long style version is used in soft or weak masonry to better develop strength. The Lag Shield™ is not recommended for overhead or life safety applications.
-
BrandDeWALT®
-
UPC075352012056
-
Manufacturer Part Number01205-PWR
-
CountryUSA|Canada
-
Tensile Strength2370 lb
-
Thread Length1-7/8 in
-
MaterialZamac Alloy
-
Minimum Embedment Depth3 in
-
TypeLong
-
Shear Strength1600 lb
-
Diameter1/2 in
-
Drill Size3/4 in
-
Overall Length2 in
- Internally threaded anchor for easy bolt removability and service work
- Ultimate load capacity: 1460 lb tensile strength when embedded in 2000 psi, 2110 lb tensile strength when embedded in 4000 psi and 2370 lb tensile strength when embedded in 6000 psi compressive strength concrete
- Ideal for use in masonry materials
| Competitor Name | Competitor Part Number |
|---|---|
| Fastenal | 2141553 |
-
Alternative Part Number01205
-
UNSPSC31162103
-
Package Description50/BX
-
Standards/ApprovalsASTM E488|GSA CID-A-A-1923A Type 1
-
Specification Sheet
