Southwire - Topaz 1221 SCH 40 Junction Box, 4-3/8 in H x 4-3/8 in W x 2-3/8 in D, Screw Cover, NEMA 1/3/3S/4/4X/5/6/6P NEMA Rating, PVC
Topaz's 4" x 4" x 2" PVC products are strong and long lasting; precisely fabricated for optimal safety during installations. Our Schedule 40 PVC Junction Box is a surface mounted enclosure, designed without entrance hubs, to allow multiple conduit connections and wire splices made within. See product spec sheet for more details.
-
BrandSouthwire - Topaz
-
UPC751338233874
-
Manufacturer Part Number1221
-
CountryUSA
-
MaterialPVC
-
ColorGray
-
TypeSCH 40
-
Mounting TypeWall
-
NEMA RatingNEMA 1/3/3S/4/4X/5/6/6P
-
Height4-3/8 in
-
Cover TypeScrew
-
Width4-3/8 in
-
Depth2-3/8 in
-
Capacity32.04 cu-in
-
Dimensions2 in H x 4.4 in W x 4.4 in D
-
Size4 x 4 x 2 in
-
Suitable For Use WithElectrical Devices and Fixtures
- A 4 in round enclosure with four entrance hubs which can be surface mounted to a wall or ceiling
- Manufactured from PVC or PPO thermoplastic molding compound and featuring foam-in-place gasket lids attached with stainless steel screws
- Type 6P enclosures are intended for indoor or outdoor use, primarily to provide a degree of protection against contact with enclosed equipment, falling dirt, hose directed water, entry of water during prolonged submersion at a limited depth and external ice formation
- Without knockout
-
Alternative Part Number9370183|18199368
-
UNSPSC39121332
-
IDEA Index ID18199368
-
Package DescriptionEACH
-
Standards/ApprovalsUL File No. E170258/E364012
-
WarrantyLimited
-
Warranty Information
-
Specification Sheet
-
Full Engineering Drawing
