Appleton® NEER™ AC95 Non-Insulated Conduit Connector With Locknut, 1/2 in Trade, For Use With Armored/FMC/Metal Clad Cable, Die Cast Zinc, Natural/Zinc Plated
Appleton® offer NEER™ zinc cable and conduit connectors for terminating flexible metal conduit in a dry location box or enclosure, or joining lengths of flexible metal conduit. Type SC straight squeeze connectors, Type AC 90 deg two screw clamp connectors and Type DC-5500 duplex, single screw, clamp connectors are used to make a termination of flexible metal conduit. Type FC set screw connectors are used to terminate 1/2 in regular wall steel or aluminum flexible conduit. Type GC screw-in connectors are for use with flexible metal conduit. Type GX screw-in connectors are used to join lengths of flexible metal conduit.
-
BrandAppleton®
-
UPC687855100958
-
Manufacturer Part NumberAC95
-
CountryUSA|Canada
-
FinishNatural/Zinc Plated
-
MaterialDie Cast Zinc
-
Trade Size1/2 in
-
ColorMetallic
-
TypeNon-Insulated
-
Angle90 deg
-
SeriesAC Series
-
Dimensions1.51 in L x 2.12 in H
-
Suitable For Use WithArmored/FMC/Metal Clad Cable
- Male hub NPS thread connection
- All center stopped
-
Alternative Part Number8988588
-
UNSPSC39121419
-
IDEA Index ID8988588
-
Package DescriptionEACH
-
Standards/ApprovalsCSA 208044|CSA C22.2 No. 18.3|NEMA FB-1|UL 514B File No. E25014
-
Specification Sheet
