Browning 32-T MPB SPROCKETS FOR #100 CHAIN BRW 100-A-32
Browning® 1110493 Single Strand Plate Type A Roller Chain Sprocket With Keyway, 1-1/4 in Dia Bore, 13.441 in OD, #100 Chain, 32 Teeth, 1-1/4 in Pitch, Steel
-
BrandBrowning®
-
UPC662289162970
-
Manufacturer Part Number1110493
-
CountryUSA
-
Pitch1-1/4 in
-
Pitch Diameter12.753 in
-
MaterialSteel
-
Chain Size#100
-
TypeSingle Strand Plate Type A
-
Number of Teeth32
-
Outside Diameter13.441 in
-
Bore Diameter1-1/4 in
- Solid plate
- No hub projection
- High quality, high carbon steel
- Browning® offers type A plate steel sprockets in single strands
- Lasts longer than sprockets made from low carbon steel
- For use with 1-1/4 in pitch ANSI chain
-
Alternative Part Number100A32
-
UNSPSC31171900
-
Package Description1/PK
-
Standards/ApprovalsANSI Specified
-
Warranty1 Year
-
Instruction/Installation Manual
-
Specification Sheet
