IDC Select® IDC F-60MM Finished Bore QD® Bushing, 60 mm Dia Bore, 4.437 in Dia Barrel, 6-5/8 in Dia Flange, 3-3/4 in OAL, Nodular Graphite Cast Iron
IDC Select® bushings are available in H, QD®, Taper-Lock®, and Split Taper™ designs and are available in inch and metric sizes. They are stocked in popular finished bore sizes. All IDC Select® bushings are fully interchangeable with industry standard design.
-
BrandIDC Select®
-
UPC887412021850
-
Manufacturer Part NumberIDC F-60MM
-
CountryUSA
-
MaterialNodular Graphite Cast Iron
-
Flange Diameter6-5/8 in
-
Flange Thickness1 in
-
Torque Rating50 ft-lb
-
TypeFinished Bore
-
Screw Size9/16-12 x 3-5/8 in
-
Barrel Diameter4.437 in
-
Keyway Size18 x 11 mm
-
Bolt Circle Diameter5-5/8 in
-
Bore Diameter60 mm
-
Overall Length3-3/4 in
- Easy installation and dismount
- Setscrew over keyway
- Most sizes can be reverse mounted
- Keystock provided with shallow key sizes
- F size QD® bushing
-
UNSPSC31171605
-
Package Description1/PK
-
Standards/ApprovalsANSI Specified|ASTM A536/A536-84|SAE Standard
-
