Gates® Power Transmission Hi-Power® II B109 Banded Heavy Duty V-Belt, B Section, 21/32 in W Top, 112 in L Outside, 13/32 in THK, EPDM
The wrapped classical section Hi-Power™ V-belt has a long reputation for reliability on agricultural and industrial applications. The arched top of the Hi-Power belt provides superior strength to prevent "dishing" and distortion of the tensile section. The cords are properly aligned, each of them carrying its full share of the load.
-
BrandGates® Power Transmission
-
UPC72053291773
-
Manufacturer Part NumberB109
-
CountryUSA|Canada
-
Pitch5 mm
-
Temperature Range-65 to 185 deg F
-
MaterialEPDM
-
Tooth ProfileCurvilinear
-
Reinforced MaterialFlex-Bonded Polyester
-
Width15 mm
-
Series9003
-
Number of Teeth163
-
Overall Length815 mm
-
Thickness13/32 in
-
Top Width21/32 in
-
TypeBanded Heavy Duty
-
Minimum Pulley Diameter4.775 in
-
Section SizeB
-
Number of Ribs1
-
Outside Length112 in
- Flex-bonded cords are strongly bonded to the body of the belt resulting in equal load distribution and the absorption of bending stress without cord deterioration
- The Flex-Weave® cover is constructed for longer cover life, providing extended protection to the core of the belt from oil, dirt and heat
- Gates® curves provide proper cord support and full contact with the sheave groove for uniform loading, uniform wear and increased belt life
- Featuring a composite, multi-purpose construction, these belts resist oil and heat, ozone, sunlight, weather and aging
| Competitor Name | Competitor Part Number |
|---|---|
| Motion Industries | 01547492 |
-
Alternative Part Number90032109
-
UNSPSC26111801
-
Package DescriptionEACH
-
Standards/ApprovalsARPM/RMA IP-3-2/IP-3-3
-
Catalog
-
Instruction/Installation Manual
