Smith Bearing® SMITH-TRAX® VCR-2-1/2 Heavy Duty Stud Type Deep Groove Ball Bearing Track Roller, 2-1/2 in Dia x 1-5/16 in W Roller, 1-1/2 in Dia Point, 3/4 in Dia x 1-3/4 in L Stud
VCR series bearings are designed to handle both axial and radial loads by using tapered roller bearings or deep groove ball bearings. These bearings should be used when standard needle roller bearings are not sufficient to handle the thrust load found in certain applications.
-
BrandSmith Bearing®
-
UPC651041192997
-
Manufacturer Part NumberVCR-2-1/2
-
CountryUSA
-
Load Capacity1100 lb Static
-
Point Diameter1-1/2 in
-
Thread Length7/8 in
-
Thread Size3/4-16 UNF-2A
-
Closure TypeUnsealed
-
TypeHeavy Duty Stud Type
-
V-Groove Angle90 deg
-
Roller Diameter2-1/2 in
-
Roller MaterialAlloy Steel
-
Roller Width1-5/16 in
-
SeriesVCR
-
Stud Diameter3/4 in
-
Stud Length1-3/4 in
-
Stud MaterialAlloy Steel
-
Stud TypeV-Grooved
-
UNSPSC31171541
-
Warranty12 months
-
