CONSOLIDATED BRG 305703-ZZ Cylindrical OD Yoke Roller, 17 mm Dia Bore, 47 mm Dia Roller x 17.5 mm W Roller
CONS 305703-ZZ Cylindrical OD Yoke Roller, 17 mm Dia Bore, 47 mm Dia Roller x 17.5 mm W Roller
-
BrandCONS
-
UPC644075207966
-
Manufacturer Part Number305703-ZZ
-
CountryUSA
-
Temperature Rating-30 to 110 deg C
-
Closure TypeShielded
-
TypeCylindrical OD
-
Roller Diameter47 mm
-
Roller Width17.5 mm
-
Bore Diameter17 mm
- Used in applications with heavier overall loads
- Double row shielded yoke type track rollers - angular contact design - contact angle of 25 deg They are equipped with two cages made from polyamide 66 material
- Double row yoke type track rollers are lubricated with a lithium base grease - operating temperature -30 deg to 110 degC
- These bearings can be relubricated, if necessary, through a lubrication hole in the inner race
-
Package DescriptionEACH
