IDEAL COPPER CRIMP ELC/CONNECTOR--BX/100 IDL 2006-S
Crimp connectors from IDEAL® are designed for making fast, permanent, pressure-type connections. Whether there is a connection in a high vibration environment or installations at an OEM, there is a solution available. The steel and copper crimp connectors cover a wide range of combinations and have available insulating caps to protect against dangerous electrical shock.
-
BrandBUCHANAN
-
UPC781789450056
-
Manufacturer Part Number2006S
-
CountryUSA
-
FinishZinc Plated
-
MaterialCopper
-
Dimensions0.211 in Dia x 0.425 in L
-
Insulation TypeNon-Insulated
-
Temperature Rating221 deg F
-
TypeSplice Cap
-
Voltage Rating600 V AC
-
Wire Size18 to 10 AWG
-
Wire TypeSolid Copper
-
Specifications(2) 18 AWG Minimum, (4) 12 AWG Max Wire Combination
- Solid copper sleeves require less crimping pressure and resistn corrosion in harsh environments
- Designed for making fast, permanent, pressure-type connections
| Competitor Name | Cross-Reference Number |
|---|---|
| Grainger | 4FA30 |
-
Alternative Part Number8304055
-
UNSPSC39121449
-
IDEA Index ID8304055
-
Standards/ApprovalsRoHS Compliant|CSA C22.2 No. 188|UL 486C|W-S-61D Federal Specification
-
RoHS
-
