HCI Preferred Supplier 940137 Gate Valve, 2 in Nominal, 11.5 TPI FNPT End Style, C37700 Forged Brass Body
HCI Preferred Supplier 940137 Gate Valve, 2 in Nominal, 11.5 TPI FNPT End Style, C37700 Forged Brass Body
-
BrandGeneric
-
Manufacturer Part Number940137
-
CountryUSA
-
Port TypeFull
-
Pressure Rating200 psi WOG/125 psi WSP
-
Top to Inlet Center5.846 in
-
MediaCold Water, Oil, Gas and Saturated Steam
-
Trim MaterialBrass/PTFE
-
Hand Wheel Diameter3.819 in
-
Nominal Size2 in
-
Inlet to Outlet Length2.677 in
-
Softgoods MaterialNBR Rubber Seat
-
Domestic/ImportImport
-
Body MaterialC37700 Forged Brass
-
End Style11.5 TPI FNPT
- Full-port design for a better water flow
- Cast iron handle
- Good for diesel fuel
- Solid wedge
- Screw-In bonnet
- Non-Rising stem
-
UNSPSC40141613
-
Package Description2/BX
-
Standards/ApprovalsANSI B1.20.1
-
