JASON 5-RC-105 CONVENTIONAL BANDED V-BELT C TYPE, 7/8 " WIDE X 105 " LONG X 5 RIBS
OUTSIDE LENGTH OF 109 "ES, 5 RIBS, MADE OF NR/SBR. THE DRIVE BELT IS THE MOST RELIABLE AND EFFICIENT. THIS BELT TRANSMITS POWER SMOOTHLY AND EFFICIENTLY DUE TO ITS CAREFUL CONSTRUCTION AND RESISTANCE TO WEAR AND TEAR.
-JAS5RC105>
