DIXON 300-D-AL 61947 Cam and Groove Fitting, 3 in Nominal, Female Coupler x FNPT End Style, Aluminum
Dixon® 300-D-AL Type D Cam and Groove Coupler, 3 in Nominal, Female Coupler x FNPT End Style, Aluminum
-
BrandGeneric
-
Manufacturer Part Number61947
-
CountryUSA
-
UPC822353033241
-
MaterialAluminum
-
Fitting/Connector TypeAdapter
-
Nominal Size3 in
-
Domestic/ImportImport
-
End StyleFemale Coupler x FNPT
-
Temperature Rating70 deg F
-
Pressure Rating125 psi
-
TypeType D
-
SeriesAL-D
-
Length3-11/16 in
- 10-3/32 in open across cam arm
- Precision machined to rigid tolerances
- Stainless pins will not rust or bind, providing great strength and safety
- Recess holds gasket firmly in place - ensures proper placement
- Long shank design allows proper banding, thus eliminating the major cause of hose damage
- Buna-N gaskets
- Durable stainless steel cam arm pins
- Produced to interchange with all product produced to commercial item description A-A-59326D
- Under no circumstances should cam and groove couplings be used for compressed air or steam service!
- Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
- 125 psi at ambient temperature 70 deg F pressure
- Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
- Do not use in connection with drinking water
- Wash hands after handling
- 356T6 Aluminum
| Competitor Name | Competitor Part Number |
|---|---|
| Grainger | 58DM49 |
-
UNSPSC40141734
-
Package Description1/PK
-
Standards/ApprovalsMil-Spec A-A-59326|ASTM spec|PROP65:This product can expose you to chemicals, including lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm
-
WarrantyLimited
-
Catalog
-
Specification Sheet
-
Technical Bulletin
