Leviton® 7090-PG 2-Circuit Electrolier Lampholder, 250 W, 250 V AC, E26 Lamp
Leviton® 7090-PG 2-Circuit Electrolier Lampholder, 250 W, 250 VAC, Medium Incandescent Lamp
-
BrandLeviton®
-
UPC078477071939
-
Manufacturer Part Number7090-PG
-
CountryUSA
-
FinishPolished Gilt
-
MaterialPhenolic
-
ColorBrass
-
Type2-Circuit Electrolier
-
Connection TypeScrew
-
Mounting TypePipe/Surface
-
Voltage Rating250 V AC
-
Dimensions1.36 in Dia
-
Lamp Base TypeE26
-
Lamp TypeIncandescent
-
Lamp Wattage250 W
- Low, medium, high OFF sequence
- 2-circuit
- Aluminum screw shell
- Brass terminal screws, thermoplastic knob
- Complete construction
- Removable turn knob operator type
- #4-36 mandrel thread, #8-32 set screw thread
- 1/8 IPS tapped bushing with set screw
| Competitor Name | Cross-Reference Number |
|---|---|
| Grainger | 25LK61 |
| 513652 |
-
Alternative Part Number7335591
-
UNSPSC39111803
-
IDEA Index ID7335591
-
Package DescriptionEACH
-
Standards/ApprovalsUL File No. E3810|CSA File No. LR1863|NOM 057
-
Specification Sheet
