Square D™ 8501KP12V20 Standard General Purpose Relay, 8 Pin, 2 Form C DPDT Contact, 120 VAC V Coil
Square D 8501 K relays are designed for multi-pole switching applications at 240 volts or lower. These relays have industry standard wiring and pin configurations that allow their use as replacements for many similar relays without wiring or hardware modifications.
-
BrandSquare D™
-
UPC785901480747
-
Manufacturer Part Number8501KP12V20
-
CountryCanada
-
Temperature Rating-40 to 131 deg F
-
Power Rating1/3 hp, 1/2 hp
-
Frequency Rating50/60 Hz
-
Coil Voltage120 VAC
-
TypeStandard
-
Contact Form2 Form C DPDT
-
Mounting TypeSocket
-
Contact Rating10 A at 28/240 VAC
-
Number of Poles2
-
Dimensions1.39 in H x 1.39 in W x 2.66 in D
- Manual operator/red pilot light options
- AC or DC operation
- 12 ms pick-up, 12 ms drop-out
- Tubular pins
- 1/3 hp at 120 VAC, 1/2 hp at 240 VAC
- Type KP
-
UNSPSC39122325
-
Standards/ApprovalsCE Marked|CSA Certified|UL Listed (with 8501NR socket)
