Proto Tools 11/16" 3/8"-DRIVE 12-PT SOCKETS PRO J-5222
Proto® TorquePlus™ J5222 Standard Length Socket, Imperial, 3/8 in Square Drive, 11/16 in
-
BrandProto®
-
UPC662679161651
-
Manufacturer Part NumberJ5222
-
CountryUSA|Canada
-
Locking TypeBall
-
FinishFull Polished
-
MaterialAlloy Steel
-
Measurement SystemImperial
-
TypeStandard Length
-
Impact RatedNo
-
Number of Points12
-
Socket End Width61/64 in
-
Socket Size11/16 in
-
Opening Depth17/32 in
-
Drive End Width61/64 in
-
Drive Size3/8 in
-
Drive TypeSquare
-
Bolt Clearance Depth11/16 in
-
Overall Length1-1/8 in
- The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners
- The TorquePlus™ configuration employs a radius corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage
- The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life and allows the user to more easily turn worn, rounded or rusted fasteners
- The TorquePlus™ design allows more torque to be put on the fastener while reducing fastener
| Competitor Name | Cross-Reference Number |
|---|---|
| Berkshire eSupply | KP4202890 |
-
UNSPSC27111704
-
Package DescriptionEACH
-
Standards/ApprovalsANSI B107.1|ASME B107.110-2012|AS954E S3.8.1|Federal Specification GGG-W-641E
