Edison GDC-40MA Low Breaking Small Dimension Time Delay Fuse With Nickel Plated Brass End Caps, 40 mA, 250 V AC, 35 A, Cylindrical Body
Edison GDC-40MA Low Breaking Small Dimension Time Delay Fuse With Nickel Plated Brass End Caps, 40 mA, 250 VAC, 35 A, Cylindrical Body
-
BrandEdison
-
UPC051712432160
-
Manufacturer Part NumberGDC-40MA
-
CountryUSA
-
Terminal TypeFerrule
-
MaterialGlass
-
Frequency Rating50 Hz
-
Rejection/Non-RejectionNon-Rejection
-
TypeLow Breaking Small Dimension
-
Mounting TypeHolder
-
Voltage Rating250 V AC
-
Amperage Rating40 mA
-
SeriesGDC
-
Indicating/Non-IndicatingNon-Indicating
-
Interrupt Rating35 A
-
Body Size5.2 mm Dia x 20 mm L
-
Body TypeCylindrical
-
ElementSingle
- 35 A at 250 VAC interrupt rating
-
Alternative Part Number8405858
-
UNSPSC39121609
-
IDEA Index ID8405858
-
Standards/ApprovalscULus Guide JDYX2/JDYX8|UL File No. E19180|IMQ File E1921|CA03.00530|MITI/JET File JET1641-31003-1005
-
Catalog
-
Specification Sheet
