Bussmann Edison ECSR4 Current Limiting Time Delay Fuse, 4 A, 600 V, 200 kAIC Interrupt, RK5 Class
Edison's UL Class RK5 dual-element, time-delay fuses provide economical solutions to overcurrent protectioni. Available in both 250Vac and 600Vac, with 200kA RMS Sym interrupting ratings and sizes ranging from 0 to 600 amp.
-
BrandEdison
-
UPC782634508205
-
Manufacturer Part NumberECSR4
-
CountryUSA
-
Terminal TypeFerrule End
-
MaterialFiberglass
-
ClassRK5
-
Response Time10 s at 500%
-
TypeCurrent Limiting Time Delay
-
Voltage Rating600 V
-
Amperage Rating4 A
-
SeriesECSR
-
Indicating/Non-IndicatingNon-Indicating
-
Interrupt Rating200 kAIC
-
Body Size0.81 in Dia x 5 in L
-
ElementDual
- Superior overload and cycling capabilities
-
UNSPSC39121606
-
IDEA Index ID11197081
-
Package DescriptionEACH
-
Standards/ApprovalsCE Marked
-
Catalog
-
Specification Sheet
