Edison EDCC15 Current Limiting Time Delay Fuse, 15 A, 600 V AC, 200 kA, Class CC
Edison offers a complete line of Class CC fuses to meet your circuit and equipment protection needs. These branch circuit rated compact fuses rated 600v, and delivering 200,000a IR Vac Sym provide excellent protection in the smallest package of any UL class of fuses. Choose from our EDCC time-delay fuses for your small horsepower motor circuits, our HCLR fast-acting for your non-inductive lighting and resistance heating loads or our HCTR time-delay fuses for your small control transformer protection.
-
BrandEdison
-
UPC782634808275
-
Manufacturer Part NumberEDCC15
-
CountryUSA
-
Terminal TypeFerrule
-
ClassCC
-
Rejection/Non-RejectionRejection
-
TypeCurrent Limiting
-
Voltage Rating600 V AC
-
Amperage Rating15 A
-
SeriesEDCC
-
Interrupt Rating200 kA
-
Body Size0.41 in Dia x 1.5 in L
- A superior all purpose space saving branch circuit fuse that meets most protection requirements up to 30 A
- Faster response to damaging short circuit currents and higher interrupt rating than mechanical over current protective devices
- Maximum 200 kA interrupt rating for available fault current in today's large capacity systems
- Helps ensure that future growth will not obsolete the system
- Time delay to avoid unwanted fuse openings from surge currents
- Fast speed of response under short circuit conditions for a high deg of current limitation
- The EDCC fuse can be sized close to full load ratings for maximum overload and short circuit protection
- Can be used where either a time delay or a fast acting fuse is needed, making selection easier and reducing spare fuse inventories for substantial cost reduction
- Superior motor protection for small horsepower motor circuits
- Proper sizing can provide type 2 in coordinated protection for NEMA and IEC motor controllers
- Motors receive maximum protection against burnout from overloads and single phasing
-
Alternative Part Number8431950
-
UNSPSC39121606
-
IDEA Index ID8431950
-
Package DescriptionEACH
-
Standards/ApprovalsUL 48-4 Guide JDDZ|UL File No. E162363|HRCI-CC|CSA C22.2 No. 248.4, Class 1422-02|CSA File No. 53787|CE Certified
-
Specification Sheet
