Littelfuse® POWR-GARD® L60030M-1C Gangable Midget Fuse Block, 600 V AC/DC, 30 A, 14 to 6 AWG Wire, 1 Pole
The Littelfuse® Class CC, CD and midget blocks offer generous space savings and enhanced value. DIN rail mounting and universal mounting holes are available as well as an indication feature on all Class CD fuse blocks.
-
BrandLittelfuse®
-
UPC079458009583
-
Manufacturer Part NumberL60030M-1C
-
CountryUSA|Canada
-
Temperature Rating125 deg C
-
MaterialThermoplastic
-
ClassCC
-
Fuse Diameter10 mm
-
Fuse Length38 mm
-
TypeGangable
-
Connection TypeBox Lug
-
Mounting TypeDIN Rail
-
Voltage Rating600 V AC/DC
-
Amperage Rating30 A
-
SeriesL600M
-
Wire Size14 to 6 AWG
-
Number of Poles1
-
Dimensions0.783 in W x 1.25 in D x 3 in H
-
Suitable For Use WithBLF, BLN, BLS, FLA, FLM, FLQ, FLU, KLK, KLKD, KLQ Series Fuse
- Midget fuse blocks are molded of high-strength, high temperature material to minimize block breakage during handling and installation, as well as damage due to heat
- Space saving design
- Universal mounting holes for easy replacement
- One hand release from DIN rail optional
- Rejection feature that prevents the insertion of fuses with lower interrupting rating or voltage ratings
- Clip design reduces resistance and heat
- 1200 V minimum dielectric strength
- Tin plated copper alloy clip/terminals, copper box lug, zinc plated steel pressure plate
- Non-DIN rail fuse blocks have interlocking feature allowing ganging for any number of poles
- Interlocking fuse blocks allow ganging to produce a fuse block with any number of poles
-
Alternative Part Number8556018
-
UNSPSC39121629
-
IDEA Index ID8556018
-
Package DescriptionEACH
-
Standards/ApprovalsUL File No. E14721|CSA File No. LR7316|PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer
-
