Jacobs® 30233 18N Super Drill Chuck, 1/8 to 3/4 in Capacity, 4JT Mounting, Ball Bearing, K4
Jacobs® 30233 18N Super Drill Chuck, 1/8 to 3/4 in Capacity, 4JT Mounting, Ball Bearing, K4
-
BrandJacobs®
-
UPC095456302334
-
Manufacturer Part Number30233
-
CountryUSA|Canada
-
Capacity1/8 to 3/4 in
-
Closed Length5.12 in
-
TypeSuper
-
Mounting Type4JT
-
Series18N
-
Bearing TypeBall
-
Open Length3.95 in
-
Key NumberK4
-
Outside Diameter3.01 in
- Jaws center-ground for absolute straightness and alignment
- Through-hardened sleeve teeth, plus hardened nose and keyholes provide outstanding wear resistance
- Steel chuck
- Each chuck 100% inspected for performance and precision
- One-piece sleeve eliminates crack between driving teeth often found in other designs
- Fluted sleeve standard
- T.I.R. 0.003 in maximum at half capacity
- Designed to work with a wide range of production drilling equipment, jig borers, milling machines, lathes and radials, this chuck is engineered for heavy duty, close tolerance production drilling
- Ball bearing construction maximizes gripping force and drilling accuracy
- Ball thrust bearings reduce friction and increase grip torque and overall performance
| Competitor Name | Cross-Reference Number |
|---|---|
| Grainger | 3L880 |
-
UNSPSC27112807
-
Package Description1/BX
-
Warranty1 Year
-
