Onyx 34855 2102M General Purpose Spiral Flute Tap, Right Hand Cutting, M16x2 Thread, D7 Thread Limit, Semi-Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, Steam Oxide, HSS

0 Ratings
$77.79
In Stock
SKU: MCT34855
noimage_new

Onyx 34855 2102M General Purpose Spiral Flute Tap, Right Hand Cutting, M16x2 Thread, D7 Thread Limit, Semi-Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, Steam Oxide, HSS

In Stock
HCI of Jackson: 1
HCI of Dyersburg: 0
HCI of Humboldt: 0
HCI of Union City: 0
HCI of Gallatin: 0
My Wishlist
Compare
Back to: Spiral Flute Taps
Main specs
  • Brand
    Onyx
  • UPC
    686125348557
  • Manufacturer Part Number
    34855
  • Country
    USA
Specification
  • Finish/Coating
    Steam Oxide
  • Thread Length
    0.745 in
  • Material
    HSS
  • Thread Limit
    D7
  • Thread Size
    M16x2
  • Chamfer Type
    Semi-Bottoming
  • Class of Fit
    D7
  • Measurement System
    Metric
  • Type
    General Purpose
  • Series
    2102M
  • Number of Flutes
    3
  • Cutting Direction
    Right Hand
  • Overall Length
    3-13/16 in
Features
  • Reduce neck design and shorter thread length for increased coolant flow to the cutting edge, enhanced chip evacuation and reduced contact between tap and workpiece
  • For tapping a wide range of materials up to 28Rc hardness
  • Steam oxide over nitride increases wear resistance, reduces friction, reduces galling and chip welding, improves chip flow and increases tap lubricant retention
  • The spiral flutes draw the chips out of the hole
  • Semi-bottoming style (2-3 thread chamfer) allows threading close to the bottom of blind holes but cuts more efficiently than standard bottoming taps due to a slightly longer chamfer which distributes the cutting load over a greater number of teeth
Competitor Information
Competitor Name Competitor Part Number
Berkshire eSupply MT7934855
Additional Information
  • UNSPSC
    23241615
  • Package Description
    1/PK
  • Standards/Approvals
    ISO 9001:2008
Reviews

There are yet no reviews for this product.
