Martin 6018 1 3/8 Bored-to-Size Roller Chain Sprocket Coupling Hub, 60 Chain, 1-3/8 in Bore Dia 18 Teeth, 4.46 in OD, 3-1/2 in Hub Dia, Steel
Roller chain couplings have a torque capacity in excess of the torque normally transmitted by shafting which falls within the coupling bore range. Select the smallest coupling, which will accommodate both shafts. For a reversing operation, shock or pulsating loads, or other severe operating conditions, select the next larger coupling size. A cover should be used to assure maximum service life, particularly if the coupling operates at high speeds or under moist conditions. For proper lubrication, fill the space between the cover and the coupling with soft to medium consistency coupling grease. Many finished bore sizes available as well as stock bore blanks that can be altered. Chains, covers stocked in all branch locations. All stock roller chain couplings have hardened teeth.
-
BrandMartin
-
UPC697950047508
-
Manufacturer Part Number6018 1 3/8
-
CountryUSA|Canada
-
MaterialSteel
-
Chain Number60
-
Maximum Speed3000 rpm
-
TypeBored-to-Size
-
Screw Size5/16-18 x 5/16 in
-
Hub Diameter3-1/2 in
-
Hub Length1-7/8 in
-
Number of Teeth18
-
Keyway Size5/16 x 5/32 in
-
Outside Diameter4.46 in
-
Length Through Bore1-7/8 in
-
Bore Diameter1-3/8 in
- Select the smallest coupling that will accommodate both shafts
- For a reversing operation, shock or pulsating loads, or other severe operating conditions, select the next larger coupling size
- Precise machining and processes ensure consistent finish and high quality
-
UNSPSC31163007
-
Package Description1/BX
-
Specification Sheet
-
Catalog
