Browning® 3789229 Single Strand Roller Chain Sprocket, 1-15/16 in Dia Bore, 39-3/8 in OD, #160 Chain, 60 Teeth, 2 in Pitch, Steel
Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.
-
BrandBrowning®
-
UPC662289286669
-
Manufacturer Part Number3789229
-
CountryUSA
-
Bushing TypeType 4 Taper Bore
-
Pitch2 in
-
Pitch Diameter38.215 in
-
MaterialSteel
-
Chain Size#160
-
TypeSingle Strand
-
Hub Diameter9.395 in
-
Number of Teeth60
-
Outside Diameter39-3/8 in
-
Length Through Bore4-1/2 in
-
Bore Diameter1-15/16 in
- This product has the Browning® exclusive twice the life guarantee
- Compact design
- Hardened teeth at no extra cost, drives sizes up to 30 teeth on 40 through 160 chain
- 1-11/16 in/ft taper
- Setscrew or cap screw acts as external key
- Flush fit, less space on shaft
- No protruding flange
- For use with 2 in pitch ANSI chain
-
Alternative Part Number160TB60
-
UNSPSC31171900
-
Package Description1/PK
-
Standards/ApprovalsANSI Specified
-
Warranty1 Year
-
Instruction/Installation Manual
-
Specification Sheet
