Browning® 3924008 Single Strand Finished Bore Type 1 Roller Chain Sprocket With Keyway, 3/4 in Dia Bore, 4.392 in OD, #35 Chain, 35 Teeth, 3/8 in Pitch, Steel
Browning® finished bore sprockets are offered in single strands. Offerings include 35 to 100 pitch range. Finished bore sprockets are available from 3/8 to 2-7/16 in. Hardened teeth are available up to 30 teeth.
-
BrandBrowning®
-
UPC662289699520
-
Manufacturer Part Number3924008
-
CountryUSA
-
Pitch3/8 in
-
Pitch Diameter4.183 in
-
MaterialSteel
-
Chain Size#35
-
TypeSingle Strand Finished Bore Type 1
-
Hub Diameter2.516 in
-
Number of Teeth35
-
Keyway Size3/16 x 3/32 in
-
Outside Diameter4.392 in
-
Length Through Bore0.859 in
-
Bore Diameter3/4 in
- Furnished with standard keyway on centerline of tooth and hollow head setscrew over keyway
- In-stock hardened sprockets are warranted to last at least twice as long as the standard (unhardened) mild steel sprockets they replace
- For use with 3/8 in pitch ANSI chain
-
Alternative Part Number3535X3/4
-
UNSPSC31171900
-
Package Description1/PK
-
Standards/ApprovalsANSI Specified
-
Warranty1 Year
-
Instruction/Installation Manual
-
Specification Sheet
