Browning® 3963618 Single Strand Finished Bore Type 1 Roller Chain Sprocket With Keyway, 1-1/2 in Dia Bore, 9.313 in OD, #50 Chain, 45 Teeth, 5/8 in Pitch, Steel
Browning® finished bore sprockets are offered in single strands. Offerings include 35 to 100 pitch range. Finished bore sprockets are available from 3/8 to 2-7/16 in. Hardened teeth are available up to 30 teeth.
-
BrandBrowning®
-
UPC662289712915
-
Manufacturer Part Number3963618
-
CountryUSA
-
Bushing TypeSplit Taper
-
Pitch5/8 in
-
Pitch Diameter8.96 in
-
MaterialSteel
-
Chain Size#50
-
TypeSingle Strand Finished Bore Type 1
-
Hub Diameter3.766 in
-
Number of Teeth45
-
Keyway Size5/16 x 5/32 in
-
Outside Diameter9.313 in
-
Length Through Bore1.078 in
-
Bore Diameter1-1/2 in
- Furnished with standard keyway on centerline of tooth and hollow head setscrew over keyway
- In-stock hardened sprockets are warranted to last at least twice as long as the standard (unhardened) mild steel sprockets they replace
- For use with 5/8 in pitch ANSI chain
-
Alternative Part Number5045X 1 1/2
-
UNSPSC31171900
-
Package Description1/PK
-
Standards/ApprovalsANSI Specified
-
Warranty1 Year
-
Specification Sheet
-
Instruction/Installation Manual
