Browning® 3790391 Single Strand Taper Bore Bushed Type 1 Roller Chain Sprocket With Hardened Teeth, 1/2 in Dia Bore, 4.098 in OD, #40 Chain, 24 Teeth, Steel
Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.
-
BrandBrowning®
-
UPC662289190478
-
Manufacturer Part Number3790391
-
CountryUSA
-
Pitch Diameter3.831 in
-
MaterialSteel
-
Chain Size#40
-
TypeSingle Strand Taper Bore Bushed Type 1
-
Hub Diameter3.016 in
-
Number of Teeth24
-
Outside Diameter4.098 in
-
Length Through Bore1 in
-
Bore Diameter1/2 in
-
Alternative Part NumberH40TB24
-
UNSPSC31171901
-
Package Description1/PK
-
Warranty1 Year
-
