Morse® 1125871 Double Strand Type DB Roller Chain Sprocket With Hardened Teeth, 2-1/2 in Dia Bore, 4.92 in OD, 50 Chain, 23 Teeth, 5/8 in Pitch, Steel
Browning®Type B minimum bore sprockets are offered in single, double and triple strands. Offerings include 25 to 200 pitch range. Minimum bore sprockets are available in bore ranges from 1/4 to 8-3/8 in.
-
BrandMorse®
-
UPC662289202379
-
Manufacturer Part Number1125871
-
CountryUSA
-
Pitch5/8 in
-
Pitch Diameter4.59 in
-
MaterialSteel
-
Chain Size50
-
TypeDouble Strand Type DB
-
Hub Diameter3-5/8 in
-
Number of Teeth23
-
Outside Diameter4.92 in
-
Length Through Bore1-7/8 in
-
Bore Diameter2-1/2 in
- Larger hub diameter allows larger bore capacity
- Slightly larger bores are possible with no keyway, shallow keyway or setscrew at angle to keyway
- For 5/8 in pitch roller chain
-
Alternative Part NumberD50B23
-
UNSPSC31171901
-
Package Description1/PK
-
Warranty1 Year
-
Catalog
-
Specification Sheet
