Browning® 1293638 Standard Riveted Roller Chain, 1-1/2 in Pitch, 7/8 in Dia x 1 in W Roller, Steel
Browning® 1293638 Standard Riveted Roller Chain, 1-1/2 in Pitch, 7/8 in Dia x 1 in W Roller, Steel
-
BrandBrowning®
-
UPC662289303632
-
Manufacturer Part Number1293638
-
CountryUSA
-
Pitch1-1/2 in
-
Plate Height1.4 in
-
Plate Thickness0.187 in
-
Tensile Strength34000 psi
-
MaterialSteel
-
TypeStandard
-
Roller Diameter7/8 in
-
Roller Width1 in
-
Number of Strands1
-
Pin Diameter0.437 in
-
Alternative Part NumberJ120 RIV 10 FT CH
-
UNSPSC26111500
-
Package DescriptionEACH
-
Standards/ApprovalsANSI Specified
-
WarrantyLimited
