Browning® 3049905 Multiple Sheave, 1/2 to 2 in QD® Bore, 4.65 in OD, 3 Grooves, 4.55 in Dia Pitch, 2-3/8 in W Face
Browning® offers an extensive multi groove sheave offering. This includes Browning® SPLIT TAPER® and QD® bushing designs. This means maximum economy and versatility for your application. Truly the right drive every time! Our exclusive B5V® sheaves have a patented design that offers 5 V hp in the economy of a B section sheave. B5V® sheaves serve 90% of all applications from 10 to 150 hp. This can reduce cost up to 40% over traditional designs.
-
BrandBrowning®
-
UPC662289468744
-
Manufacturer Part Number3049905
-
CountryUSA
-
Face Width2-3/8 in
-
Bushing TypeSDS
-
Pitch Diameter4.55 in
-
MaterialCast Iron
-
Hub Projection0.73125 in
-
Number of Grooves3
-
Outside Diameter4.65 in
-
Bore Diameter1/2 to 2 in
-
Bore TypeQD®
-
Overall Length3.10625 in
-
Suitable For Use With5V-Cross Section V-Belts
- Close grain cast iron allows Browning® to machine our sheaves to the closest tolerances possible
- Constant Speed - No slip, no creep, minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets
- Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement
- Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft, Split Taper and QD Bushing styles, as well as, finished and minimum plain bore
-
Alternative Part Number35V465SDS
-
UNSPSC24101610
-
Package DescriptionEACH
-
Warranty1 Year
-
Instruction/Installation Manual
