MasterDrive 6B70SF Type A-1 Groove Sheave, 1/2 to 2-15/16 in Dia Bore, 7.35 in Dia Outside, 6 Grooves, 6.6 in (A)/7 in (B) Dia Pitch, 4.75 in W Face
QD Heavy Duty V-Belt Sheaves are designed to be mounted with QD Bushings. The bushings allow easy installation and removal reducing downtime; as well as the versatility and cost savings of being able to use one sheave with a range of different shaft sizes by selecting from the available bushing bore sizes. The QD Bushing ensures a tight grip on the shaft minimizing the risk of slippage, and in many cases can be reverse mounted when space constraints require.
-
BrandMasterDrive
-
UPC806372010124
-
Manufacturer Part Number6B70SF
-
CountryUSA
-
Face Width4.75 in
-
Bushing TypeSF
-
Pitch Diameter6.6 in (A)/7 in (B)
-
FinishGray
-
MaterialCast Iron
-
TypeType A-1
-
Number of Grooves6
-
Outside Diameter7.35 in
-
Bore Diameter1/2 to 2-15/16 in
-
Bore TypeQD Bushed
-
Suitable For Use WithA, AX, B and BX V-Belts
- Statically Balanced
- Easy installation/removal reduces downtime
- Able to be Reverse Mounted
-
Alternative Part Number2105008895
-
Package DescriptionEACH
