FYH® UCPAN206 19 UCPAN Normal Duty Pillow Block Unit, 3 in L Bolt Center-to-Center, 1-11/16 in Base to Bore Centerline, 3-27/32 in OAL 3-7/32 in OAH
FYH® UCPAN206 19 UCPAN Normal Duty Pillow Block Unit, 3 in L Bolt Center-to-Center, 1-11/16 in Base to Bore Centerline, 3-27/32 in OAL 3-7/32 in OAH
-
BrandFYH®
-
Manufacturer Part NumberUCPAN206 19
-
CountryUSA
-
Load Capacity19.5 kN Dynamic/11.3 kN Static
-
Locking DeviceSet Screw
-
TypeNormal Duty
-
SeriesUCPAN
-
Base Width1-1/2 in
-
Base to Bore Centerline1-11/16 in
-
Bolt Center-to-Center Length3 in
-
Bore TypeCylindrical
-
Overall Height3-7/32 in
-
Overall Length3-27/32 in
-
Overall Width1-1/2 in
