LF-GT-104 Dodge® 136352 207 Normal Duty Non-Expansion Ball Bearing Unit With Square Bolt Holes, 1-1/4 in Dia Bore, 3.94 in Dia Bolt Circle, 3-Bolt Base Flange Mount, 4.81 in OAL/Dia
The Dodge® Grip-Tight® mounted ball bearing is the maintenance-friendly solution for all of your ball bearing application needs, capable of performing critical functions in many operations. Grip-Tight® mounted ball bearings offer a unique method of shaft attachment via a thin wall tapered adapter sleeve and locknut design. Because of this system, bearing assemblies may be installed and removed from a shaft easily. 360 deg of concentric grip on the shaft for the entire length-through-bore of the bearing means Grip-Tight® provides a tight press fit with no shaft damage, even on commercial grade shafting.
-
BrandDodge®
-
UPC782475996674
-
Manufacturer Part Number136352
-
CountryUSA
-
Load Capacity5759 lb Dynamic/3461 lb Static
-
Locking DeviceGrip-Tight® Adapter Mounted
-
Flange Mounting Type3-Bolt Base
-
Maximum Speed9500 rpm
-
TypeNormal Duty Non-Expansion
-
Seal MaterialNitrile Rubber
-
Series207
-
Bearing MaterialSteel
-
Bolt Circle Diameter3.94 in
-
Bore Diameter1-1/4 in
-
Overall Depth1.62 in
-
Overall Length/Diameter4.81 in
- Patented pull/push thin wall Grip-Tight® adapter system
- Ideal for high-speed applications in which concentricity is important
- Little or no bearing vibration at high speeds
- More efficient fan balancing
- Decreased labor during removal with no shaft reconditioning
- Alleviates setscrew issues due to vibration
- Wide inner ring design, thin wall adapter locking
- Reduced shafting costs
- Inventory savings
- Patented DualGuard™ seal, featuring the rubberized flinger is standard
- Light duty flange
| Competitor Name | Competitor Part Number |
|---|---|
| Applied Industrial Technologies | 101014383 |
| Motion Industries | 03711873 |
-
Alternative Part NumberLF-GT-104
-
UNSPSC31171504
-
Package DescriptionEACH
-
Standards/ApprovalsUL Listed
-
WarrantyLimited
-
Specification Sheet
-
Owners/User Manual
-
Instruction/Installation Manual
-
Warranty Information
-
Catalog
