FYH® NANF209 28 NANF Cylindrical Flange Mount Ball Bearing Unit, 1-3/4 in Dia Bore, 4-9/64 in L Bolt Center-to-Center, 4-Bolt Flange Flange Mount, 5-13/32 in OAL/Dia
FYH® NANF209 28 NANF Cylindrical Flange Mount Ball Bearing Unit, 1-3/4 in Dia Bore, 4-9/64 in L Bolt Center-to-Center, 4-Bolt Flange Flange Mount, 5-13/32 in OAL/Dia
-
BrandFYH®
-
Manufacturer Part NumberNANF209 28
-
CountryUSA
-
Load Capacity34.1 kN Dynamic/21.3 kN Static
-
Locking DeviceEccentric Locking Collar
-
Flange Mounting Type4-Bolt Flange
-
TypeCylindrical
-
SeriesNANF
-
Bearing MaterialCast Iron
-
Bolt Center-to-Center Length4-9/64 in
-
Bore Diameter1-3/4 in
-
Overall Depth2-5/16 in
-
Overall Length/Diameter5-13/32 in
