FYH® UCF309 28 UCF Cylindrical Flange Mount Ball Bearing Unit, 1-3/4 in Dia Bore, 4-59/64 in L Bolt Center-to-Center, 3/4 in Dia Bolt Circle, 4-Bolt Flange Flange Mount, 6-5/16 in OAL/Dia
FYH® UCF309 28 UCF Cylindrical Flange Mount Ball Bearing Unit, 1-3/4 in Dia Bore, 4-59/64 in L Bolt Center-to-Center, 3/4 in Dia Bolt Circle, 4-Bolt Flange Flange Mount, 6-5/16 in OAL/Dia
-
BrandFYH®
-
Manufacturer Part NumberUCF309 28
-
CountryUSA
-
Load Capacity48.9 kN Dynamic/29.5 kN Static
-
Locking DeviceSet Screw
-
Flange Mounting Type4-Bolt Flange
-
TypeCylindrical
-
SeriesUCF
-
Bearing MaterialCast Iron
-
Bolt Center-to-Center Length4-59/64 in
-
Bolt Circle Diameter3/4 in
-
Bore Diameter1-3/4 in
-
Overall Depth2-3/8 in
-
Overall Length/Diameter6-5/16 in
