Koyo 1204 Caged Cylindrical Bore Light Self-Aligning Ball Bearing, 20 mm Dia Bore, 47 mm OD, 2 Rows, 14 mm W, 9.9 kN Dynamic/2.65 kN Static Load
Self-aligning ball bearings have a spherical outer ring raceway, the center of whose curvature meets that of the bearing itself, so that the inner ring, balls and cage continue to rotate, aligning themselves if they have become misaligned within design limits.
-
BrandKoyo
-
UPC605790000867
-
Manufacturer Part Number1204
-
CountryUSA
-
Load Capacity9.9 kN Dynamic/2.65 kN Static
-
Cage MaterialPressed Steel
-
Maximum Speed14000 rpm Grease/17000 rpm Oil
-
Closure TypeOpen
-
TypeCaged Cylindrical Bore Light
-
Width14 mm
-
Series12 Series
-
Number of Rows2
-
Outside Diameter47 mm
-
Bore Diameter20 mm
- This type of bearing is suitable when the displacement of the centers around which the shaft and housing rotate and shaft deflection are likely to occur
- Bearing with a tapered bore can easily be fit to the shaft with an adapter assembly
-
UNSPSC31171532
-
Standards/ApprovalsABEC1 Class P0
-
